首頁 TXC晶振

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振

產品簡介

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振，AB系列SMD，縫封晶體，5.0* 3.2* 0.9 mm ，特點，可靠的縫封陶瓷封裝。工作溫度范圍寬。惡劣環境下性能優越可靠。應用范圍:TPMS, ECM, ABS，傳感器模塊。符合rohs標準/不含鉛臺灣TXC晶振公司，晶技晶振，無源晶振，5032晶振，AB-16.000MALE-T晶振，汽車晶振，汽車電動天窗控制系統晶振，臺灣晶振，貼片晶振，四腳晶振，石英晶振，高品質晶振，車載多媒體晶振，行車記錄儀晶振，低損耗晶振，耐高溫晶振，耐沖擊晶振。

產品詳情

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振，AB系列SMD，縫封晶體，5.0* 3.2* 0.9 mm，特點，可靠的縫封陶瓷封裝。工作溫度范圍寬。惡劣環境下性能優越可靠。應用范圍:TPMS, ECM, ABS，傳感器模塊。符合rohs標準/不含鉛臺灣TXC晶振公司，晶技晶振，無源晶振，5032晶振，AB-16.000MALE-T晶振，汽車晶振，汽車電動天窗控制系統晶振，臺灣晶振，貼片晶振，四腳晶振，石英晶振，高品質晶振，車載多媒體晶振，行車記錄儀晶振，低損耗晶振，耐高溫晶振，耐沖擊晶振。

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振

型號 AB
頻率范圍 8 ~ 50 MHz
工作模式 Fundamental
頻率容差 ± 10 ppm, ± 20 ppm, ±50 ppm Max
溫度范圍內的頻率穩定度 ± 150 ppm Max.
工作溫度 - 40 ~ +125 ℃
驅動電平 10 μW (typical) ; 300 μW (Max.)
負載電容 12 pF, or specify
儲存溫度范圍 - 40 ~ +125 ℃
可靠性標準 AEC-Q200

臺產晶技晶振,AB-16.000MALE-T晶振,車載香薰系統晶振

AB

AB

TXC原廠編碼 生產商品牌 Series 頻率 頻率穩定度 頻率容差 負載電容 工作溫度
AB-16.000MALE-T TXC晶振 AB 16MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-25.000MAGE-T TXC晶振 AB 25MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-12.000MALE-T TXC晶振 AB 12MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-24.000MAGE-T TXC晶振 AB 24MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-16.000MAGE-T TXC晶振 AB 16MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-13.225625MAGE-T TXC晶振 AB 13.225625MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-8.000MAGK-T TXC晶振 AB 8MHz ±50ppm ±30ppm 20pF -40°C ~ 85°C
AB-20.000MAHJ-T TXC晶振 AB 20MHz ±30ppm ±30ppm 18pF -40°C ~ 85°C
AB-13.560MENE-T TXC晶振 AB 13.56MHz ±50ppm ±10ppm 12pF -40°C ~ 125°C
AB-24.576MAGQ-T TXC晶振 AB 24.576MHz ±50ppm ±30ppm 10pF -40°C ~ 85°C
AB-19.680MALE-T TXC晶振 AB 19.68MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-26.000MAGE-T TXC晶振 AB 26MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-37.500MAGE-T TXC晶振 AB 37.5MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-13.560MAGE-T TXC晶振 AB 13.56MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-15.360MAGE-T TXC晶振 AB 15.36MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-18.000MAGH-T TXC晶振 AB 18MHz ±50ppm ±30ppm 15pF -40°C ~ 85°C
AB-18.432MAGE-T TXC晶振 AB 18.432MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-20.000MAGE-T TXC晶振 AB 20MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-27.000MAGE-T TXC晶振 AB 27MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-11.0592MAGQ-T TXC晶振 AB 11.0592MHz ±50ppm ±30ppm 10pF -40°C ~ 85°C
AB-13.560MALE-T TXC晶振 AB 13.56MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-10.000MAGE-T TXC晶振 AB 10MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-12.000MAGE-T TXC晶振 AB 12MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-12.000MAME-T TXC晶振 AB 12MHz ±100ppm ±30ppm 12pF -40°C ~ 125°C
AB-13.125MAME-T TXC晶振 AB 13.125MHz ±100ppm ±30ppm 12pF -40°C ~ 125°C
AB-13.225625MAHE-T TXC晶振 AB 13.225625MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
AB-13.528750MAHQ-T TXC晶振 AB 13.52875MHz ±30ppm ±30ppm 10pF -40°C ~ 85°C
AB-13.560MAHE-T TXC晶振 AB 13.56MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
AB-13.560MANE-T TXC晶振 AB 13.56MHz ±50ppm ±30ppm 12pF -40°C ~ 125°C
AB-13.560MANH-T TXC晶振 AB 13.56MHz ±50ppm ±30ppm 15pF -40°C ~ 125°C
AB-13.580MANE-T TXC晶振 AB 13.58MHz ±50ppm ±30ppm 12pF -40°C ~ 125°C
AB-16.000MAME-T TXC晶振 AB 16MHz ±100ppm ±30ppm 12pF -40°C ~ 125°C
AB-16.000MAPJ-T TXC晶振 AB 16MHz ±50ppm ±30ppm 18pF -40°C ~ 105°C
AB-16.000MENQ-T TXC晶振 AB 16MHz ±50ppm ±10ppm 10pF -40°C ~ 125°C
AB-16.000MFNE-T TXC晶振 AB 16MHz ±50ppm ±15ppm 12pF -40°C ~ 125°C
AB-16.0132MEMQ-T TXC晶振 AB 16.0132MHz ±100ppm ±10ppm 10pF -40°C ~ 125°C
AB-18.000MAHH-T TXC晶振 AB 18MHz ±30ppm ±30ppm 15pF -40°C ~ 85°C
AB-18.080MEME-T TXC晶振 AB 18.08MHz ±100ppm ±10ppm 12pF -40°C ~ 125°C
AB-19.707894MENV-T TXC晶振 AB 19.707894MHz ±50ppm ±10ppm 8pF -40°C ~ 125°C
AB-20.000MAHE-T TXC晶振 AB 20MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
AB-20.000MALE-T TXC晶振 AB 20MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-22.600MEMQ-T TXC晶振 AB 22.66MHz ±100ppm ±10ppm 10pF -40°C ~ 125°C
AB-24.000MAHE-T TXC晶振 AB 24MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
AB-24.19066MENE-T TXC晶振 AB 24.19066MHz ±50ppm ±10ppm 12pF -40°C ~ 125°C
AB-24.576MEHQ-T TXC晶振 AB 24.576MHz ±30ppm ±10ppm 10pF -40°C ~ 85°C
AB-25.000MDHI-T TXC晶振 AB 25MHz ±30ppm ±20ppm 16pF -40°C ~ 85°C
AB-25.000MDPE-T TXC晶振 AB 25MHz ±50ppm ±20ppm 12pF -40°C ~ 105°C
AB-14.31818MAHQ-T TXC晶振 AB 14.318MHz ±30ppm ±30ppm 10pF -40°C ~ 85°C
AB-14.31818MAME-T TXC晶振 AB 14.318MHz ±100ppm ±30ppm 12pF -40°C ~ 125°C
AB-16.000MANE-T TXC晶振 AB 16MHz ±50ppm ±30ppm 12pF -40°C ~ 125°C
AB-19.200MAGE-T TXC晶振 AB 19.2MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-19.68750MEME-T TXC晶振 AB 19.687MHz ±50ppm ±30ppm 12pF -40°C ~ 125°C
AB-24.000MAPE-T TXC晶振 AB 24MHz ±50ppm ±30ppm 12pF -40°C ~ 105°C
AB-8.000MANV-T TXC晶振 AB 8MHz ±50ppm ±30ppm 8pF -40°C ~ 125°C
AB-8.192MAHJ-T TXC晶振 AB 8.192MHz ±30ppm ±30ppm 18pF -40°C ~ 85°C
AB-14.31818MALE-T TXC晶振 AB 14.31818MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-10.000MALE-T TXC晶振 AB 10MHz ±150ppm ±30ppm 12pF -40°C ~ 125°C
AB-14.318180MAHK-T TXC晶振 AB 14.31818MHz ±30ppm ±30ppm 20pF -40°C ~ 85°C
AB-14.318180MAME-T TXC晶振 AB 14.31818MHz ±100ppm ±30ppm 12pF -40°C ~ 125°C
AB-19.2000MAGE-T TXC晶振 AB 19.2MHz ±50ppm ±30ppm 12pF -40°C ~ 85°C
AB-19.687500MEME-T TXC晶振 AB 19.6875MHz ±100ppm ±10ppm 12pF -40°C ~ 125°C
AB-20.000MAMK-T TXC晶振 AB 20MHz ±100ppm ±30ppm 20pF -40°C ~ 125°C
AB-24.576MEIQ-T TXC晶振 AB 24.576MHz ±20ppm ±10ppm 10pF -40°C ~ 85°C
AB-26.000MEIE-T TXC晶振 AB 26MHz ±20ppm ±10ppm 12pF -40°C ~ 85°C
AB-27.000MAHE-T TXC晶振 AB 27MHz ±30ppm ±30ppm 12pF -40°C ~ 85°C
AB-28.63636MAMJ-T TXC晶振 AB 28.63636MHz ±100ppm ±30ppm 18pF -40°C ~ 125°C
AB-37.500MEHD-T TXC晶振 AB 37.5MHz ±30ppm ±10ppm 11pF -40°C ~ 85°C
AB-37.500MEHE-T TXC晶振 AB 37.5MHz ±30ppm ±10ppm 12pF -40°C ~ 85°C
AB-40.000MDHE-T TXC晶振 AB 40MHz ±30ppm ±20ppm 12pF -40°C ~ 85°C
