12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器
頻率：30MHz
尺寸：7.0mm x 5.0mm
12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器,丹麥格耶KXO-V97T振蕩器以工業級穩定性為核心亮點,針對12.94437型號晶振進行專項優化,可在高低溫波動,機械振動等復雜工業環境下保持穩定輸出.產品具備出色的溫度適應性,能在較寬溫度范圍內(如-40℃~85℃)維持頻率偏差在極小范圍,適配PLC,工業傳感器晶振,數控設備等工業場景.同時,格耶嚴格的生產質控流程,從原材料篩選到成品檢測均層層把關,確保每臺KXO-V97T振蕩器都具備低失效率,長壽命的工業級品質.
訂購熱線：0755-27837162
12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器
丹麥格耶KXO-V97T振蕩器具備出色的兼容性,可靈活適配不同品牌,不同型號的主控芯片與電路系統,12.94437產品采用標準化接口設計,便于工程師快速集成到現有電路中,無需大幅調整設計方案,降低研發與生產周期.此外,其穩定的頻率輸出特性,能與各類外設精準配合,保障智能計量設備,工業通信模塊等場景的數據處理與信號傳輸效率.融入低功耗晶振設計理念,能有效降低設備整體能耗,適配便攜式工業檢測設備,無線傳感終端等需電池供電的場景.其緊湊的封裝結構可節省PCB板空間,便于在小型化設備中集成,同時無源相關特性(若適用,可根據實際補充)進一步簡化電路設計,減少外圍元件需求,既降低成本,又提升電路運行的穩定性,為低功耗設備的長時間續航提供有力支持.
12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器
| 原廠型號 Originalmodel： |
          12.94437
|
品牌brand： |
                     丹麥格耶Geyer
|
| Manufacturer品牌 |
  Geyer晶振
|
OperatingTemperature溫度 | -40℃~+85℃ |
| Series型號 |
   KXO-V97T
|
Current-Supply(Max) | - |
| Type類型 | XO | PackageHeight高度 | 1.3mm |
| Frequency頻率 |
  30M
|
Termination 腳位 |
 4-pad
|
| 輸出方式 Output： | - | PackageType 封裝類型 | 4-SMD |
| Voltage-Supply電壓 | 3.3V | Packaging 包裝 | TapeandReel |
| FrequencyStability頻率穩定度 |
      ±100PPm
|
安裝方式 Installation： | Surfacemount |
| Size/Dimension尺寸 | 7050mm | 最小包裝數MPQ： | 1000 |
12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器
12.94437晶振,丹麥格耶Geyer晶振,KXO-V97T振蕩器
| 12.87000 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87001 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87002 | KX-327V | 1.25 | 1.05 | 0.5 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.036/°C² ±10% |
| 12.87034 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 4 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87080 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87081 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87083 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87086 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 6 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87090 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87095 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87105 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87107 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87109 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12 pF | ± 15 ppm | -0.042/°C² ±10% |
| 12.87110 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87111 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87112 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87113 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.042/°C² ±10% |
| 12.87114 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87115 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87116 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.042/°C² ±10% |
| 12.87118 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87119 | KX-327S | 8.2 | 3.8 | 2.5 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87120 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87121 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.034/°C² ±10% |
| 12.87123 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87126 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87127 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 30 ppm | -0.042/°C² ±10% |
| 12.87128 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 6 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87129 | KX-327XS | 4.95 | 1.82 | 0.96 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.042/°C² ±10% |
| 12.87130 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87131 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87132 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87133 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87134 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87135 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87136 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87137 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.033/°C² ±10% |
| 12.87138 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.033/°C² ±10% |
| 12.87139 | KX-327L | 7.0 | 1.5 | 1.4 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.033/°C² ±10% |
| 12.87143 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87144 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 5.0 ppm | -0.035/°C² ±10% |
| 12.87145 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87146 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87147 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87148 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87149 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87150 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87151 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 9 pF | ± 30 ppm | -0.035/°C² ±10% |
| 12.87152 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87153 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87155 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 30 ppm | -0.035/°C² ±10% |
| 12.87157 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.035/°C² ±10% |
| 12.87158 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 10 ppm | -0.035/°C² ±10% |
| 12.87159 | KX-327NH | 3.2 | 1.5 | 0.8 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.035/°C² ±10% |
| 12.87160 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87161 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 5.0 ppm | -0.030/°C² ±10% |
| 12.87163 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 7 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87164 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 30 ppm | -0.030/°C² ±10% |
| 12.87165 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 9 pF | ± 20 ppm | -0.030/°C² ±10% |
| 12.87166 | KX-327R | 2.0 | 1.2 | 0.6 mm | 32.768 kHz | 12.5 pF | ± 20 ppm | -0.04/°C² |
